Camso Sprocket
Engineered to perfectly match Camso tracks, Camso Sprocket are built tough in order to optimize track life and provide the lowest operating cost solution. Available in North America only.
| PID | Camso Part Number | OEM Part Number | Number Of Teeth | Pitch |
Shape B=Bell F=Flat |
Number of Bolt Holes | Weight | |
|---|---|---|---|---|---|---|---|---|
| in | lbs | |||||||
| 147.1.1 | SP-015086BA | 7166679 | 15 | 3.39 | B | 12 | 52.9 | |
| true | 147.14.14 | SP-015086BB | 7165111 | 15 | 3.39 | B | 6 | 50.7 |
| 147.2.2 | SP-015086FA | 304-1870 | 15 | 3.39 | F | 12 | 30.9 | |
| 147.3.3 | SP-015086FB | V051121110 | 15 | 3.39 | F | 9 | 37.5 | |
| 147.20.20 | SP-015086FC | 7204050 | 15 | 3.39 | F | 15 | 30.9 | |
| 147.19.19 | SP-015086FD | 7270159 | 15 | 3.39 | F | 16 | 35.3 | |
| 147.4.4 | SP-016086FA | T239479 | 16 | 3.39 | F | 8 | 39.7 | |
| 147.6.6 | SP-017086BA | 7165109 | 17 | 3.39 | B | 6 | 61.7 | |
| 147.7.7 | SP-017086FA | T254141 | 17 | 3.39 | F | 10 | 44.1 | |
| 147.8.8 | SP-017086FB | 304-1916 | 17 | 3.39 | F | 12 | 44.1 | |
| 147.9.9 | SP-017086FC | T239480 | 17 | 3.39 | F | 8 | 48.5 | |
| 147.10.10 | SP-017086FD | V061121112 | 17 | 3.39 | F | 9 | 48.5 | |
| 147.11.11 | SP-017086FE | 47378993 | 17 | 3.39 | F | 8 | 52.9 | |
| 147.18.18 | SP-017086FF | 7227421 | 17 | 3.39 | F | 8 | 50.7 |
